SDK reference
The OpenAPI spec is the source of truth. Stainless generates each SDK from it, so method names and parameter shapes are consistent across languages once you account for casing conventions (camelCase in TypeScript, snake_case in Python, PascalCase in Go).
Base URL
https://api.limrun.comOverride with a per-client option in TypeScript, Python, or Go.
Authentication
Every request authenticates with a single API key (prefix lim_). Generate keys at console.limrun.com.
The CLI and every SDK accept the key from the LIM_API_KEY environment variable by default:
curl https://api.limrun.com/v1/ios_instances \
-H "Authorization: Bearer $LIM_API_KEY"import Limrun from '@limrun/api';
const lim = new Limrun({
apiKey: process.env['LIM_API_KEY'], // defaults to LIM_API_KEY env, can be omitted
});from limrun_api import Limrun
client = Limrun(
api_key=os.environ.get("LIM_API_KEY"), # defaults to LIM_API_KEY env, can be omitted
)import (
"github.com/limrun-inc/go-sdk"
"github.com/limrun-inc/go-sdk/option"
)
client := limrun.NewClient(option.WithAPIKey("...")) // defaults to LIM_API_KEY envexport LIM_API_KEY=lim_...Credentials
Two credentials show up in most workflows. Mixing them up is the most common integration bug.
| Credential | Where you get it | Use for |
|---|---|---|
Org API key (lim_...) | console.limrun.com → Settings → API Keys; lim login; or LIM_API_KEY | REST control plane (api.limrun.com), including create/list/delete. Also MCP: Authorization: Bearer <org API key> on instance.status.mcpUrl. |
Per-instance token (instance.status.token) | Returned in status when the instance is ready | apiUrl device daemon, endpointWebSocketUrl (append ?token=), adbWebSocketUrl, sandbox.xcode.url, and SDK helpers like Ios.createInstanceClient. Embedded in signedStreamUrl for browser streaming. |
The org API key must never ship to a browser or end-user client. For embedded simulators, your backend holds the API key and passes only endpointWebSocketUrl + status.token to <RemoteControl />. See Embed the simulator.
Install snippets
If you'd rather skip the SDK, call the API directly with curl. No install required.
# npm
npm install @limrun/api
# pnpm
pnpm add @limrun/api
# bun
bun add @limrun/apipip install limrun_apigo get -u github.com/limrun-inc/go-sdk@latest# npm
npm install --global @limrun/cli
# pnpm
pnpm add --global @limrun/cli
# bun
bun add --global @limrun/cliSDK capability matrix
The three SDKs are not equivalent. Every one covers the control plane (create / get / list / delete instances and assets). Beyond that, only the TypeScript SDK is complete; the others vary. The CLI is the easiest fallback for anything your SDK doesn't cover; raw HTTP is the universal escape hatch.
| Capability | TypeScript | Python | Go |
|---|---|---|---|
| Instance CRUD (iOS, Android, Xcode) | ✓ | ✓ | iOS + Android only (no XcodeInstances service) |
| Asset CRUD | ✓ | ✓ | ✓ |
assets.getOrUpload (MD5 dedup + signed PUT) | ✓ | upload manually | ✓ (Assets.GetOrUpload) |
| iOS device control (taps, screenshot, element-tree, typeText, simctl streaming, ...) | ✓ | use REST or CLI | ✓ (subset, see below) |
| Android device control over the SDK | ✓ | use REST + ADB | use REST + ADB |
| ADB tunnel for Android | ✓ (startAdbTunnel) | use external adb | ✓ (tunnel.NewADB, plus Multiplexed) |
Xcode source-sync + remote xcodebuild | ✓ (xcodeInstances.createClient) | use lim xcode build | use lim xcode build |
| iOS reverse tunnel | ✓ (startReverseTunnel) | not supported | not supported |
| iOS app-log streaming | ✓ | not supported | not supported |
| iOS video recording | ✓ | not supported | not supported |
| StoreKit local-config helpers | ✓ | not supported | not supported |
The Go iOS WebSocket client (github.com/limrun-inc/go-sdk/websocket/ios) covers screenshot, element-tree, tap, tap-element, type-text, press-key, launch-app, list-apps, open-url, install-app, lsof, set-orientation, increment/decrement/set element value, and simctl streaming. It does not include terminate-app, scroll, performActions, or video recording today.
If you're on Python and need any of the device-control or build surfaces, the canonical option is the lim CLI from @limrun/cli (shell out from your code) or raw REST calls against the URLs returned in instance.status. The CLI is feature-complete; the SDKs catch up later.
Errors
Errors are returned as JSON with an HTTP status code that maps to a typed error class in every SDK.
| Status | TypeScript / Python / Go | Meaning |
|---|---|---|
400 | BadRequestError | Malformed input or invalid combination of parameters. |
401 | AuthenticationError | Missing or invalid API key. |
403 | PermissionDeniedError | API key lacks the necessary permission. |
404 | NotFoundError | The instance, asset, or other resource does not exist. |
409 | ConflictError | Conflicting state (e.g. instance already terminated). |
422 | UnprocessableEntityError | Validation error: request shape is valid but semantically rejected. |
429 | RateLimitError | Rate limit hit. Retry with backoff. |
≥500 | InternalServerError | Server-side issue. SDKs auto-retry by default. |
| n/a | APIConnectionError | Network failure before a response. |
| n/a | APIConnectionTimeoutError | Request timed out. |
| n/a | APIUserAbortError | The request was aborted by the caller. |
The SDKs auto-retry on 408, 409, 429, 5xx, and connection errors. The default is 2 retries with exponential backoff. Configure or disable with the per-client maxRetries option.
import Limrun from '@limrun/api';
const lim = new Limrun({ maxRetries: 5 });
try {
const instance = await lim.iosInstances.create({ wait: true });
} catch (err) {
if (err instanceof Limrun.APIError) {
console.log(err.status, err.name, err.headers);
} else {
throw err;
}
}Query params: wait and reuseIfExists
Two query params show up on every create call across resources.
| Param | Type | Meaning |
|---|---|---|
wait | boolean | Return only after the instance reaches ready. Without wait, the call returns immediately with state: 'creating'. |
reuseIfExists | boolean | If an instance with the same (region, labels) exists, return it instead of creating a new one. |
Use wait: true for interactive workflows where you need the URLs immediately. Use reuseIfExists: true whenever you want repeated calls (CLI re-runs, retries, the same PR's CI runs) to converge on the same instance.
Instance state machine
Every iOS, Android, and Xcode instance moves through the same lifecycle, from creating while hardware is being provisioned, through assigned while it boots, to ready when the URLs in status are usable, and finally to terminated.
creating ──┬──► assigned ──► ready ──► terminated
│
└──► (error) ──► terminated (status.errorMessage set)| State | Meaning |
|---|---|
unknown | Default placeholder; should not be returned for live instances. |
creating | Provisioning. URLs in status are not yet populated. |
assigned | Hardware has been assigned; instance is booting. |
ready | Fully booted. All URLs populated. Safe to connect a control client. |
terminated | Stopped, either by explicit delete, inactivity timeout, hard timeout, or error. |
instance.status.errorMessage is set when the instance terminated due to an error.
Status URL surface
Every successful wait: true create returns a status block with the URLs the data plane needs.
| Field | iOS | Android | Xcode | Use |
|---|---|---|---|---|
token | ✓ | ✓ | ✓ | Per-instance bearer for apiUrl, endpointWebSocketUrl, adbWebSocketUrl, sandbox.xcode.url; embedded in signedStreamUrl. |
apiUrl | ✓ | ✓ | ✓ | HTTP base for the per-instance device daemon (SDK / CLI control client). |
signedStreamUrl | ✓ | ✓ | Browser watch URL with token embedded (no org API key in the browser). | |
endpointWebSocketUrl | ✓ | ✓ | WebSocket for <RemoteControl />; pass ?token=<status.token>. | |
mcpUrl | ✓ | ✓ | Per-instance MCP HTTP endpoint. Auth with org API key header, not status.token. See MCP. | |
adbWebSocketUrl | ✓ | ADB tunnel endpoint. Pass as adbUrl to createInstanceClient. | ||
targetHttpPortUrlPrefix | ✓ | ✓ | Reverse-proxy prefix for tunneled HTTP ports (used by Appium/WDA). | |
sandbox.xcode.url | ✓ (conditional) | Xcode sandbox API URL when spec.sandbox.xcode.enabled: true. | ||
sandbox.playwrightAndroid.url | ✓ (conditional) | CDP URL when spec.sandbox.playwrightAndroid.enabled: true. |
Regions and labels
spec.region pins an instance to a region (e.g. eu-north1, us-east1). If omitted, Limrun schedules based on spec.clues and current availability. The console's Analytics tab breaks down runtime minutes per platform and per region, which is the canonical place to see which regions an org has used:

metadata.labels is a free-form { [key: string]: string } map. The same labels do three jobs at once: they identify instances for reuseIfExists, they filter listings via labelSelector (a comma-separated key=value list), and they group instances for bulk operations like "delete everything tagged pr=42."
Useful label keys for most workflows are tenant, user, session, pr, repo, agent, and managed_by. Avoid keys that might overlap with metadata Limrun adds internally.
Resources × CRUD
The four resources (iosInstances, androidInstances, xcodeInstances, assets) all support the same five operations. Method names follow each language's convention.
Create an iOS instance
curl -X POST "https://api.limrun.com/v1/ios_instances?wait=true&reuseIfExists=true" \
-H "Authorization: Bearer $LIM_API_KEY" \
-H "Content-Type: application/json" \
-d '{
"metadata": { "labels": { "session": "demo" } },
"spec": {
"model": "iphone",
"region": "us-west",
"sandbox": { "xcode": { "enabled": true } }
}
}'const instance = await lim.iosInstances.create({
wait: true,
reuseIfExists: true,
metadata: { labels: { session: 'demo' } },
spec: {
model: 'iphone',
region: 'us-west',
sandbox: { xcode: { enabled: true } },
},
});instance = client.ios_instances.create(
wait=True,
reuse_if_exists=True,
metadata={"labels": {"session": "demo"}},
spec={
"model": "iphone",
"region": "us-west",
"sandbox": {"xcode": {"enabled": True}},
},
)// The Go SDK does not expose `model` on the create params yet.
// Instances default to iPhone. To pick iPad or Apple Watch, use the CLI or REST.
instance, err := client.IosInstances.New(ctx, limrun.IosInstanceNewParams{
Wait: param.NewOpt(true),
ReuseIfExists: param.NewOpt(true),
Metadata: limrun.IosInstanceNewParamsMetadata{
Labels: map[string]string{"session": "demo"},
},
Spec: limrun.IosInstanceNewParamsSpec{
Region: param.NewOpt("us-west"),
Sandbox: limrun.IosInstanceNewParamsSpecSandbox{
Xcode: limrun.IosInstanceNewParamsSpecSandboxXcode{
Enabled: param.NewOpt(true),
},
},
},
})lim ios create --reuse-if-exists --xcode \
--model iphone --region us-west \
--label session=demoList iOS instances
curl "https://api.limrun.com/v1/ios_instances?labelSelector=session%3Ddemo&state=ready" \
-H "Authorization: Bearer $LIM_API_KEY"// Auto-paginating
for await (const inst of lim.iosInstances.list({ labelSelector: 'session=demo', state: 'ready' })) {
console.log(inst.metadata.id);
}
// Single page
const page = await lim.iosInstances.list({ limit: 50 });
for (const inst of page.items) console.log(inst.metadata.id);
while (page.hasNextPage()) {
const next = await page.getNextPage();
// ...
}for inst in client.ios_instances.list(label_selector="session=demo", state="ready"):
print(inst.metadata.id)iter := client.IosInstances.ListAutoPaging(ctx, limrun.IosInstanceListParams{
LabelSelector: param.NewOpt("session=demo"),
State: param.NewOpt("ready"),
})
for iter.Next() {
inst := iter.Current()
fmt.Println(inst.Metadata.ID)
}lim ios list --label-selector "session=demo" --state readyGet / Delete an iOS instance
curl https://api.limrun.com/v1/ios_instances/<id> -H "Authorization: Bearer $LIM_API_KEY"
curl -X DELETE https://api.limrun.com/v1/ios_instances/<id> -H "Authorization: Bearer $LIM_API_KEY"const inst = await lim.iosInstances.get(id);
await lim.iosInstances.delete(id);inst = client.ios_instances.get(id)
client.ios_instances.delete(id)inst, _ := client.IosInstances.Get(ctx, id)
_ = client.IosInstances.Delete(ctx, id)lim ios get <id>
lim ios delete <id> # or `lim ios delete` for the last-createdAndroid instances
The Android operations have the same shape as iOS. Substitute androidInstances (TS), android_instances (Python), AndroidInstances (Go), or lim android * (CLI). The Android-specific pieces are clues accepting { kind: 'OSVersion', osVersion: '13'|'14'|'15' }, the multi-asset shapes on initialAssets, and spec.sandbox.playwrightAndroid.enabled.
Xcode instances
The TypeScript and Python SDKs expose a top-level xcodeInstances / xcode_instances resource with the same CRUD shape as iOS. The Go SDK does not ship an XcodeInstances service today; reach the same instances through one of these paths:
- Set
spec.sandbox.xcode.enabled: truewhen creating an iOS instance and use the iOS resource on the SDK; the Xcode sandbox URL comes back atinstance.status.sandbox.xcode.url. - Or call
POST /v1/xcode_instancesdirectly over HTTP. - Or shell out to
lim xcode create/lim xcode build.
Assets
Assets use getOrCreate (upsert; named GetOrNew in Go) and getOrUpload (upsert plus actual upload) instead of create. The os field on Asset is optional; leaving it unset means the asset is available for both platforms. The getOrUpload helper that handles MD5 dedup and the signed PUT ships in the TypeScript and Go SDKs; Python callers do the two-step pattern manually (call get_or_create, then PUT the bytes to signedUploadUrl if md5 is missing or doesn't match).
# Two-step upload: get-or-create returns a signed PUT URL, then push the bytes to it.
curl -X PUT https://api.limrun.com/v1/assets \
-H "Authorization: Bearer $LIM_API_KEY" \
-H "Content-Type: application/json" \
-d '{ "name": "my-app.tar.gz" }'
# returns signedUploadUrl + signedDownloadUrl
curl -X PUT "$SIGNED_UPLOAD_URL" \
-H "Content-Type: application/octet-stream" \
--data-binary @./my-app.tar.gz// One-shot: getOrUpload computes MD5, skips re-upload if unchanged
const asset = await lim.assets.getOrUpload({ path: './my-app.tar.gz', name: 'my-app.tar.gz' });
// Manual two-step
const asset2 = await lim.assets.getOrCreate({ name: 'my-app.tar.gz' });
if (!asset2.md5) {
await fetch(asset2.signedUploadUrl, {
method: 'PUT',
body: await fs.promises.readFile('./my-app.tar.gz'),
headers: { 'Content-Type': 'application/octet-stream' },
});
}
// List
const list = await lim.assets.list({ namePrefixFilter: 'my-app-', includeDownloadUrl: true });
// Get / delete
const a = await lim.assets.get(id, { includeDownloadUrl: true });
await lim.assets.delete(id);upserted = client.assets.get_or_create(name="my-app.tar.gz")
# ... PUT bytes to upserted.signed_upload_url ...
listed = client.assets.list(name_prefix_filter="my-app-", include_download_url=True)
fetched = client.assets.get(id, include_download_url=True)
client.assets.delete(id)// Helper: getOrUpload
asset, _ := client.Assets.GetOrUpload(ctx, limrun.AssetGetOrUploadParams{
Path: "./my-app.apk",
})
// Or lower-level: GetOrNew, then PUT to signedUploadUrl yourself.
list, _ := client.Assets.List(ctx, limrun.AssetListParams{
NamePrefixFilter: param.NewOpt("my-app-"),
IncludeDownloadURL: param.NewOpt(true),
})
got, _ := client.Assets.Get(ctx, id, limrun.AssetGetParams{IncludeDownloadURL: param.NewOpt(true)})
_ = client.Assets.Delete(ctx, id)lim asset push ./my-app.tar.gz --name my-app-v1.tar.gz
lim asset list --name my-app-v1.tar.gz --download-url
lim asset list <id>
lim asset pull <id_or_name> --output ./downloads/
lim asset delete <id>Auto-pagination
list endpoints in TypeScript, Python, and Go return iterable objects you can range over directly.
for await (const inst of lim.iosInstances.list()) {
console.log(inst.metadata.id);
}for inst in client.ios_instances.list():
print(inst.metadata.id)iter := client.IosInstances.ListAutoPaging(ctx, limrun.IosInstanceListParams{})
for iter.Next() {
fmt.Println(iter.Current().Metadata.ID)
}OpenAPI spec
The REST API is documented on lim.run and in each SDK's generated reference (typescript-sdk/api.md, python-sdk/api.md, go-sdk/api.md). The SDKs are generated from the OpenAPI spec via Stainless.
Timeouts, retries, logging
All three SDKs default to a 5-minute request timeout and 2 retries with exponential backoff. Configure both per-client with the timeout and maxRetries options, or override per-request.
The TypeScript SDK also accepts a logger and logLevel ('debug' | 'info' | 'warn' | 'error' | 'off'), settable through the LIMRUN_LOG env var. At 'debug' the SDK logs full HTTP requests and responses. Auth headers are redacted, but sensitive data in request and response bodies is not, so keep that in mind before turning debug logging on in production.
Next steps
Quickstart
The 3-minute path from npm install to a running simulator with your app on it.
Run an iOS Simulator
The data-plane surface that lives behind instance.status.apiUrl.
Run an Android Emulator
ADB tunnel and Android device-control surface.
CLI for coding agents
Every lim command tuned for agent workflows.
Was this guide helpful?
